Team Name | : | FormulaDIT |
University | : | DIT Bolton Street |
Class | : | Class 1 |
Car Number | : | 36 |
Country | : | Ireland |
FormulaDIT is delighted to be making their return to the premier Formula Student competition in which they first competed in 2010.
As the sole representative from the Republic of Ireland, the team of 14 dedicated final year undergraduate students from the School of Mechanical and Design Engineering at the Dublin Institute of Technology aim to achieve their best finish yet through Engineering innovation, focused teamwork and the support of their generous sponsors. 2016 heralds the beginning of a new and exciting chapter in the history of FormulaDIT with the introduction of Yamaha single cylinder engine and ten inch wheels along with further integration of carbon fibre components. These changes and many more have all contributed towards the 2016 challenger achieving the best ever power to weight ratio for the team. FomulaDIT would like to thank the Dublin Institute of Technology, the DIT Foundation, National Instruments, North Dublin Motorcycles, Track Day Performance, Assured Performance International, CADFEM Ireland, Cleancarb, Swift Composites, Easy Composites, Rock West Composites, Granitize Aviation, Action Adhesives, Abbey seals and Red Bull.
Length, width, height, wheelbase | 2490mm 1290mm 1280mm 1540mm |
Track (front/rear)1200mm/1100mm | 1080mm/1100mm |
Weight of car (no driver) | 180kg |
Weight distribution including 68kg driver (front/rear) | 80/100 |
Suspension (front/rear) | Double unequal length A-Arm, Single plane push rod with horizontal orientated damper |
Tyres (front/rear) | 7.0/16.0-10 Avon |
Wheels (front/rear) | 10” Keizer 7” wide, 4 stud, aluminium |
Brakes (front/rear) | Stainless Steel, hub mounted, 192 mm dia, drilled |
Chassis construction | One piece tubular spaceframe |
Engine (Electric motor for alternatively fuelled vehicles) | 2004 Yamaha WR450 four stroke single cylinder |
Bore/stroke/cylinders/cc (Electric motor spec for alternatively fuelled vehicles) | 100mm 634mm 1 476cc |
Fuel type (Type of Energy Storage for alternatively fuelled vehicles) | 99 RON unleaded |
Fuel system (Accumulator Spec for alternatively fuelled vehicles) | Yamaha fuel injector controlled by Motec M400 ECU |
Max power/max torque | 32 kW @ 8,000 rpm 37 Nm @ 7,000 rpm |
Transmission | Single 520 Chain |
Differential | Drexter LSD |
Final drive | 4.27:1 |
