Team Name | : | ISAT Formula Team |
University | : | University of Burgundy – ISAT |
Class | : | Class 1 |
Car Number | : | 58 |
Country | : | France |
The 2016 ISAT Formula Team, entirely renewed with 31 new passionate students, all in their first year of the engineering curriculum.
They represent the only French public engineering school specialized in Automotive! After a year of hard work, we participate to the FS and FSG competitions with our Internal Combustion Engine single seat car, while the French FSE is being developed within our premises. Since 2003, ISAT team have succeeded one another and we hope we can do better than our predecessors. We reach the TOP 20 in both competitions. This year, our priority is the reliability of the engine, which is developed on a bench, and the making of a new wiring harness including an advanced data acquisition system. We also focused on lowering the centre of gravity and reducing the weight. We would also like, with the other French teams, to organise a Formula Student competition in France to promote this project. To this end, a “Formula Student Press Day” took place on the Nevers Magny-Cours Circuit to communicate and initiate the organization of this competition.
Length, width, height, wheelbase | 2572mm 1215mm 1364mm 1500mm |
Track (front/rear)1200mm/1100mm | 1200mm/1150mm |
Weight of car (no driver) | 200kg |
Weight distribution including 68kg driver (front/rear) | 128.6/139.4 |
Suspension (front/rear) | Pull-rod with a motion ratio, damper TTX 25 mk2 FSAE |
Tyres (front/rear) | Hoosier 6.0/18.0-10 R25B |
Wheels (front/rear) | Mad’in 10 inches diameter 6.5 inches width, Aluminium |
Brakes (front/rear) | Fr : Beringer Caliper d32 mm Rr : AP racing Caliper d25,4mm AP Racing Master cylinder |
Chassis construction | Tubular Steel Space Frame, 25CrMo4S |
Engine (Electric motor for alternatively fuelled vehicles) | Yamaha XJ6 |
Bore/stroke/cylinders/cc (Electric motor spec for alternatively fuelled vehicles) | 66.5mm 44.5mm 4 599.8cc |
Fuel type (Type of Energy Storage for alternatively fuelled vehicles) | 98 RON unleaded |
Fuel system (Accumulator Spec for alternatively fuelled vehicles) | Student designed / built with Yamaha injection system using Bosch MS4 ECU |
Max power/max torque | 51 kW @ 9,000 rpm 56 Nm @ 7,000 rpm |
Transmission | Single 520 chain |
Differential | Drexler Limited slip, 51% for drive and 42% for deceleration |
Final drive | 3:1 |
