Team Name | : | Team Hare |
University | : | University of Huddersfield |
Class | : | Class 1 |
Car Number | : | 12 |
Country | : | UK |
The University of Huddersfield have been involved in FSUK since 1999, having initially only entered as a Class 2 project. The team were fortunate enough to win this competition outright in their first year and therefore the University has fielded a Class 1 entry ever since. HARE-16 will rather appropriately be the 16th car built by the team and represents many years of development and team growth. This year, we have chosen to refine the concept set out in 2012 whereby a drastic change from the 4 cylinder CBR engine to the lighter KTM single cylinder was selected. The main emphasis ever since has been to minimize weight wherever possible and this has seen the team make extensive use of composite materials, as well as develop clever and unique ways in which to package our designs. Last year this was recognized with the award of “Best Installation of an IC engine” by Mercedes AMG HPP, a fantastic achievement from a relatively small team and one of which we are particularly proud of! This year will see a refinement of this design, with great emphasis put on reliability in the dynamic events alongside improved suspension geometry, electronics and drive-ability.
Length, width, height, wheelbase | 2825mm, 1115mm, 1350mm 1510mm |
Track (front/rear)1200mm/1100mm | 350mm/1350mm |
Weight of car (no driver) | 180kg |
Weight distribution including 68kg driver (front/rear) | 120/ 128 |
Suspension (front/rear) | Double non-parallel unequal A-arm. Pull/Push rod actuated Ohlins TTX25 dampers |
Tyres (front/rear) | 20.5x7x13 R25B C2500 Hoosiers |
Wheels (front/rear) | 7×13 O.Z. Racing Superleggera FSAE Special, 1pc Aluminium |
Brakes (front/rear) | Floating Steel 222/215, Drilled |
Chassis construction | One piece, TIG welded CDS tubular spaceframe |
Engine (Electric motor for alternatively fuelled vehicles) | 2014/KTM 500 EXC, four stroke, single cylinder |
Bore/stroke/cylinders/cc (Electric motor spec for alternatively fuelled vehicles) | 95mm / 72mm / 1/ 510cc |
Fuel type (Type of Energy Storage for alternatively fuelled vehicles) | 99 RON Unleaded |
Fuel system (Accumulator Spec for alternatively fuelled vehicles) | Bosch |
Max power/max torque | 46.2 kW / 50 N.m |
Transmission | 520 Chain, KTM Gearbox |
Differential | Drexler Salisbury Type LSD |
Final drive | 3.3 : 1 |
