Team Name : Projecto FST Novabase
University : University of Lisbon
Class : Class 1
Car Number : 150
Country : Portugal

The FST 06e was designed with reliability as a main philosophy. After a few reliability problems which kept our 5th prototype from achieving its potential, the team decided that a step back was required in order to take 2 steps ahead. This meant simplifying the design and increasing the safety factor for most parts. The result is a car which breaks down less, and in which faults can be found and repaired easily.

Our team is comprised of roughly 40 Mechanical, Electrical and Aerospace engineering students, organized in 7 different areas – Management, Chassis, Suspension, Aerodynamics & Cooling, Vehicle Dynamics, Electronics and Powertrain. Our main goal is to increase our performance – both in technical terms and in terms of soft skills and team management. Logistics aren’t easy – Portugal is further from most FS competitions than most European teams – but we usually have fun in the trip.

Length, width, height, wheelbase 2961mm, 1187mmmm, 1480mm 15585mm
Track (front/rear)1200mm/1100mm  1200mm/1200mm
Weight of car (no driver) 290kg
Weight distribution including 68kg driver (front/rear) 130/ 160
Suspension (front/rear) Double unequal length A-Arm. Push rod actuated vertically oriented spring and damper / Double unequal length A-Arm. Push rod actuated horizontally oriented spring and damper
Tyres (front/rear) 456×190,5-254 HOOSIER R25B/456×190,5-254 HOOSIER R25B
Wheels (front/rear)  203mm wide, 2 pc carbon fiber rim and aluminium center
Brakes (front/rear) Aluminium machined AP Racing Callipers, floating 170mm diameter rotors, drilled
Chassis construction Carbon fiber Monocoque
Engine (Electric motor for alternatively fuelled vehicles) 2x 50kW permanent magnet AC motor
Bore/stroke/cylinders/cc (Electric motor spec for alternatively fuelled vehicles)
Fuel type (Type of Energy Storage for alternatively fuelled vehicles)
Fuel system (Accumulator Spec for alternatively fuelled vehicles) Honda, Single Rail indirect fuel injection
Max power/max torque 100 kW / 880 N.m
Transmission Single speed planetary
Differential
Final drive 4.1:01
