Team name: FormulaDIT
University: Dublin Institute of Technology
Class: Class 1
Car Number: 101
Country: Ireland
Official Facebook
Length: 2410
Height: 1200
Width: 1400
Wheelbase: 1545
Track: 1200/1140
Car Weight: 235
Weight Distribution: 115/120
Suspension: Front: Double unequal length A-arm, push rod actuation to horizontally mounted FOX spring dampers with anti-roll bar system.
Rear: Double unequal length A-arm, pull rod actuation to vertically mounted FOX spring damper with anti-roll bar system.
Tyres: Hoosier 20.5 x 7.0-13
Wheels: 3 piece wheel, Single nut centre locking (Student made)
Brakes: AP Racing calipers; 4 pot front and 2 pot rear. 220mm dia. drilled steel alloy discs
Chassis: One piece tubular spaceframe
Engine: Suzuki GSXR 600 (K6) Turbocharged four stroke in line four
Bore: 67
Stroke: 42
Cylinders: 4
CC: 599
Fuel Type: 99 RON unleaded
Fuel System: Student built single rail multi point fuel injection
Max Power: 71 kW @9,300 rpm
Max Torque: 77 Nm @8,500 rpm
Transmission: Single 520 chain
Differential: Drexler V2 limited slip differential
Final Drive: 3.85:1
