Team Name | : | Queen Mary Formula Student |
University | : | Queen Mary University of London |
Class | : | Class 1 |
Car Number | : | 123 |
Country | : | United Kingdom |
Queen Mary Formula Student (QMFS) is a brand new team comprising of 32 dedicated students from different backgrounds, ranging from engineering to business disciplines.
Under the leadership and engineering expertise of our Project Manager Raghu Subra, the team has been able to build a single seat formula style car. With the strong infrastructure, organisation and support provided by Head of Operations Aqil Hussain, this will be the first year of the newly restructured team entering the competition. The team aims to gain vital experience that will allow the team to develop and be more competitive in the following years. In addition, the team intends to develop both academically and professionally from the experience. The car itself is constructed from mild steel rather than alloy steel due to the welding process providing a much better finish and leaving no requirement for heat treatment to relieve stress. Moreover, the chassis was designed so that all the suspension A-arms would be mounted at chassis nodes to improve the stress distribution. QMFS would like to thank all the support that they have received from the team members, department staff and companies who have helped them build the University’s first formula style car.
Length, width, height, wheelbase | 2499.20mm 1500mm 1323.22mm 1570mm |
Track (front/rear)1200mm/1100mm | 1165mm/1135mm |
Weight of car (no driver) | 232kg |
Weight distribution including 68kg driver (front/rear) | 135/165 |
Suspension (front/rear) | Double unequal length A-Arms with pushroad actuated horizontally orientated spring and damper. |
Tyres (front/rear) | 6.2/20.0-13 Avon |
Wheels (front/rear) | 6″ wide 1 pc Aluminium Rim |
Brakes (front/rear) | Cast Iron, Hub Mounted 228.6mm diameter / Cast Iron. Hub Mounted 220mm diameter |
Chassis construction | One piece tubular spaceframe |
Engine (Electric motor for alternatively fuelled vehicles) | 2001 Triumph TT600 inline 4 cylinder 4 stroke |
Bore/stroke/cylinders/cc (Electric motor spec for alternatively fuelled vehicles) | 68mm 41.3mm 4 599cc |
Fuel type (Type of Energy Storage for alternatively fuelled vehicles) | 9Unleaded Petrol |
Fuel system (Accumulator Spec for alternatively fuelled vehicles) | Triumph multipoint fuel injection |
Max power/max torque | 110PS@12750rpm 68Nm@11000rpm |
Transmission | 525 chain |
Differential | Quaife limited slip differential |
Final drive | 3:1 |
