| Team Name | : | Formula UEM |
| University | : | Universidad Europea de Madrid |
| Class | : | Class 1 |
| Car Number | : | 83 |
| Country | : | Spain |
“Formula UEM is a multidisciplinary team made up of around 70 students of Universidad Europea de Madrid.
Our people belong to different faculties. Many of us are mechanical, electrical or civil engineers, as well as from the arts & architecture departments. For our community management we rely on business administration, journalism, and marketing students. Formula UEM team accepts students of all degree years in order to transmit the knowledge acquired by the veterans to the new students of our university.
Our team is divided in 7 sub teams: Powertrain, Suspensions, Bodywork, CAD&CAE, Electronics, Chassis and Marketing & Sponsorships. We work daily together involving each of our members in a complete workshop experience, in which quality and teamwork are the mottos. Improvement and innovation are what motivate us to go beyond the frontiers.
Banco Santander Universidad’s and Universidad Europea de Madrid are our main sponsors. Furthermore, we proudly have national and international companies supporting us such as SKF, Tyre Consortium, Loctite, TexTreme, WD-40, RS, i-Alpe, Roberlo, Altran, Aquarena, Igus, AVL, Altair and SolidWorks. Their collaboration and support have been vital and can be appreciated on the vehicle performance.”
| Length, width, height, wheelbase | 2715mm 1105mm 1150mm 1603mm |
| Track (front/rear)1200mm/1100mm | 1310mm/1248mm |
| Weight of car (no driver) | 197kg |
| Weight distribution including 68kg driver (front/rear) | 132/133 |
| Suspension (front/rear) | Ohlins TTX 25 MKII Front: Double unequal length A-Arm. Push rod spring and damper Rear: Double unequal length A-Arm. Push rod spring and damper |
| Tyres (front/rear) | Hoosier, R25B, 8”-18 x7.5-10/Hoosier, R25B, 8”-18 x7.5-10 |
| Wheels (front/rear) | Wheel 10”, BRAID ALLOY, 6’’, TO 9 ½’’ WIDE OFFSET |
| Brakes (front/rear) | Front/Rear: masters pump Tilton 74-750U/ front calipers / ISR 22-048/ rear calipers ISR 22-028 |
| Chassis construction | two piece, tubular steel spaceframe (AISI 4130) – TIG Welding and carbon fibre monocoque |
| Engine (Electric motor for alternatively fuelled vehicles) | 2007 / Honda CBR 600 RR (moto2) four stroke in line four |
| Bore/stroke/cylinders/cc (Electric motor spec for alternatively fuelled vehicles) | 67mm 42.5mm 4 599cc |
| Fuel type (Type of Energy Storage for alternatively fuelled vehicles) | Ethanol E85 |
| Fuel system (Accumulator Spec for alternatively fuelled vehicles) | Student Adapted common rail 4 injectors |
| Max power/max torque | 88.1 Kw @ 13.500 rpm 66 Nm @ 11.250 rpm |
| Transmission | Single 428 chain |
| Differential | Self–locking Drexler Part number: 100-100-00-255 |
| Final drive | 3,583:1 |
