Team Name :

ION Racing UiS

University :

University of Stavanger

Class : Class 1
Car Number : 67
Country : Norway

ION Racing is the now the largest student project at the University of Stavanger consisting of 50 students from various programs, primarily from electrical and mechanical engineering.

Weight reduction and improved aerodynamics as well as better overall performance has been the key focus of ION Racing this year. Our car features a carbon fibre monocoque, titanium wheel hubs, carbon fibre suspension and a new lighter accumulator. We also manufactured our own carbon fibre rims with aluminium centres and designed a much lighter tractive system than last years car. This summer we want to show everyone that we strive to challenge ourselves by creating something that is both faster and more agile than before, but still keeping a timeless and beautiful design. Using calculations and our engineering skills we have made a fast, lightweight car with high down force, and high stiffness. It is also reliable and safe, thanks to our amazing team, and our amazing sponsors.

Length, width, height, wheelbase 3206mm, 1156mmmm, 1470mm 1710mm
Track (front/rear)1200mm/1100mm  1275mm/1252mm
Weight of car (no driver) 205kg
Weight distribution including 68kg driver (front/rear) 133/ 140
Suspension (front/rear)

Double uequal length A-Arm suspension with push rod and actuated dampers front and rear.

Tyres (front/rear)

Hoosier R25B 20.5×7.0-13

Wheels (front/rear)

178mm wide, 3 pc carbon fiber rim with aluminuim center

Brakes (front/rear)

Steel hub mounted 227mm dia. Drilled disk brakes front and rear. 4 piston ISR caliper front, 2 piston rear.

Chassis construction

Monocoque

Engine (Electric motor for alternatively fuelled vehicles)

Emrax 228 MV

Bore/stroke/cylinders/cc (Electric motor spec for alternatively fuelled vehicles)

Electric / 400v / battery accumulator / with 288 LPA045135 cells

Fuel type (Type of Energy Storage for alternatively fuelled vehicles) Electric
Fuel system (Accumulator Spec for alternatively fuelled vehicles) 7 KW
Max power/max torque

70KW @ 5000RPM 240Nm @ 2000RPM

Transmission

Pararell gear system

Differential

Drexler LSD

Final drive 4.09:1
