Team name: Formula UEM
University: Universidad Europea de Madrid
Class: Class 1
Car Number: 183
Country: Spain
Official Website | Facebook | Twitter
Length: 1120
Height: 1530
Width: 2800
Wheelbase: 1600
Track: 1310 / 1238
Car Weight: 225
Weight Distribution: 108kg/ 117
Suspension: Ohlins TTX 25
Front: Double Arm Wishbone/ Push-rod /Upper Spring-Damper
Rear: Double Arm Wishbone / Pus-hrod / Lower Spring-Damper
Tyres: Hoosier, R25B, 13″-20.5×7.0
Wheels: 13″, 1 Piece, Carbon Fiber, Student Made
Brakes: Front: Hub mounted /steel, hub mounted, 221mm/160 mm / Tilton 74-750U
Rear: Hub mounted /steel, hub mounted, 221mm/160 mm / Tilton 74-750U
Chassis: One piece tubular steel spaceframe – TIG Welding
Engine: 2005 / Honda CBR 600 RR four stroke in line four
Bore: 67.0
Stroke: 42.5
Cylinders: 4
CC: 599
Fuel Type: Ethanol E85
Fuel System: Student Adapted common rail 4 injectors
Max Power: 88.1 Kw @ 13.500 rpm
Max Torque: 66 Nm @ 11.250 rpm
Transmission: Sigle 520 chainv
Differential: Self–locking Drexler
Final Drive:4:1
Team Profile:
Formula UEM is a multidisciplinary team compound by around 80 students of Universidad Europea de Madrid. Our people belong to different schools, many of us are mechanical, electrical or civil engineers, others are from the arts & architecture departments, whereas for our community management we rely on business administration and journalism students.
Our team is divided in 7 sub teams including Powertrain, Suspensions, Bodywork, Aerodynamics, Electronics, Chassis and Press & Sponsorships. We work daily together involving each of our members in a complete workshop experience, in which quality and teamwork are the mottos. Improvement and innovation is what motivates us to go beyond the frontiers.
Banco Santander is our main sponsor. Following, we proudly count with national and international companies such as SKF, Honda, Tire Consortion, Loctite, TexTreme, WD-40, Axon, RS, i-Alpe, Fiberflight, Roberlo, Wera, Sodexo and so many more. Their collaboration and support have been vital and can be appreciated on the vehicle performance.
Additional Information
The main team objectives that have determined our design are reliability, lightness and affordability, never refusing to supply as many driving facilities as possible. All team members are committed to the objectives in every step they take.
Carbon fibre is the material of our bodywork and many other parts such as the seat or wheels. We are known in our campus because of the manufacturing experience acquired and recently we have participated in the Laureate Award for Excellence in Robotics Engineering by making the case of a guidance robot.
