| Team Name | : | Racing Team Pilsen |
| University | : | University of West Bohemia |
| Class | : | Class 1 |
| Car Number | : | 60 |
| Country | : | Czech Republic |
UWB Racing Team Pilsen is a student team of the University of West Bohemia in Pilsen. The University was founded in 1949 and it changed into its present form in 1991.
The Formula Student project was created at the university in 2009. A new team was established this year after a two-year break. Our new car consists of steel space frame and is equipped with engine Yamaha – YZF-R6 2013. The engine is equipped with a new timing of camshafts and a dry sump system. We have made a few adjustments on the engine such as increasing the compression ratio by reducing the cylinder heads height and polishing the exhaust channels. The new shift system is operated by compressed gas and equipped with an automatic clutch. The 39th place at the Formula UK 2013 is our best result so far. Our general sponsors are the University of West Bohemia and Faculty of Mechanical Engineering, Mubea, ZF Engineering and many others. All of our partners deserve our great thanks.
| Length, width, height, wheelbase | 2875mm 1175mm 1460mm 1565mm |
| Track (front/rear)1200mm/1100mm | 1220mm/1180mm |
| Weight of car (no driver) | 245kg |
| Weight distribution including 68kg driver (front/rear) | 145/168 |
| Suspension (front/rear) | Front and rear: Double unparalleled nonunequal length A-Arm opereted by push rod. Position of dampers are horizontal. |
| Tyres (front/rear) | Front and rear: Keizerwheels; 3 pc Al Rim; R10x7,5 |
| Wheels (front/rear) | Front and rear : Hoosier 18.0 x 7.5 |
| Brakes (front/rear) | Front: ISR 22-048 4-piston; Rear: ISR 22-049 2-piston; Front/ rear brake discs: |
| Chassis construction | One piece tubular spaceframe |
| Engine (Electric motor for alternatively fuelled vehicles) | Yamaha YZF-R6 2013 |
| Bore/stroke/cylinders/cc (Electric motor spec for alternatively fuelled vehicles) | 67mm 42.5mm 4 599.4cc |
| Fuel type (Type of Energy Storage for alternatively fuelled vehicles) | RON |
| Fuel system (Accumulator Spec for alternatively fuelled vehicles) | Yamaha multi point fuel injection, 4 injectors |
| Max power/max torque | 62@10,600rpm 58@8,900rpm |
| Transmission | Single 520 chain |
| Differential | Drexler |
| Final drive | 4,5:1 |
