| Team Name | : |
YTU Racing |
| University | : |
Yildiz Technical University |
| Class | : | Class 1 |
| Car Number | : | 34 |
| Country | : | Turkey |
| Length, width, height, wheelbase | 2723mm, 1383mmmm, 1600mm 1600mm |
| Track (front/rear) | 1200mm/1200mm |
| Weight of car (no driver) | 250kg |
| Weight distribution including 68kg driver (front/rear) | 152/ 166 |
| Suspension (front/rear) |
Double unequal length A-Arms, push rod actuated Öhlins TTX MkII spring and dampers front and rear, ARB front and rear |
| Tyres (front/rear) |
180/530-13 Pirelli / 180/530-13 Pirelli |
| Wheels (front/rear) | 7 x 13 – OZ Racing, Aluminum Rim, 25 mm offset |
| Brakes (front/rear) |
Hub mounted steel, 240 mm dia. front / 210 mm dia. rear drilled floating brake discs, 4 piston front, 2 piston rear calipers |
| Chassis construction |
One piece tubular steel spaceframe |
| Engine (Electric motor for alternatively fuelled vehicles) |
2008/Honda CBR600RR four stroke in line four |
| Bore/stroke/cylinders/cc (Electric motor spec for alternatively fuelled vehicles) |
max. 10000rpm / 42.5mm / 4 / 600cc |
| Fuel type (Type of Energy Storage for alternatively fuelled vehicles) | 95 RON unleaded |
| Fuel system (Accumulator Spec for alternatively fuelled vehicles) |
Student designed & built multipoint fuel injection |
| Max power/max torque |
60 kW @ 11.000 rpm / 54 nm @ 9.000 rpm |
| Transmission |
Single 520 Chain |
| Differential |
Drexler FSAE limited slip differential |
| Final drive |
3.80:1 |
