Team name: ELiTH Racing
University: Linkoping University
Class: Class 1
Car Number: 76
Country: Sweden
Official Website | Facebook | Twitter
Length: 2900
Height: 1250
Width: 1400
Wheelbase: 1600
Track: 1200/1160
Car Weight: 235
Weight Distribution: 163/140
Suspension: Double unequal length A-arms, push/push-rod,horizontally/horizontally oriented spring and damper in separate subframe.
Tyres: Hoosier 20.0 x 7.5-13
Wheels: 13×7.5″ Keizer magnesium wheels
Brakes: Cast iron, hob mounted, drilled, floating, 240mm dia./Cast iron, differential mounted, drilled, floating, 210mm dia.
Chassis: Tubular onepiece CrMo spaceframe
Engine: 2008 / Honda CBR600RR four stroke in line four cylinder
Bore: 67
Stroke: 42.5
Cylinders: 4
CC: 599
Fuel Type: 99 RON unleaded
Fuel System: Student built ECU system based on FreeEMS
Max Power: 67kW / 60Nm
Max Torque: 10500rpm / 8000rpm
Transmission: Single 520 chain
Differential: FSAE Drexler limited slip differential
Final Drive: 3.46:1
Team profile
ELiTH Racing is the Formula Student team of Linköping University, the city of the JAS Gripen jet fighter, competing in Formula Student for the third year in a row. This year has been a transitional year for ELiTH Racing, focusing on evolving from a newcomer into becoming a steady competitor by strengthening the management structure and revising our project model.
ER14, the 2014 car, has been designed to be reliable and resource efficient. Following testing data from previous cars, the ER14 design decisions have been based on a combination of empirical experience and theoretical expertise. Due to the access to water jet cutting and additive manufacturing, many parts have been designed to accommodate these manufacturing methods.
Lastly, we would like to thank all sponsors, Formula widows/widowers and parents who stands by and helps us fulfill our dreams of becoming better engineers! More info at www.ELiTHRacing.se!
