Team name: Projecto FST Novabase
University: University of Lisbon
Class: Class 1
Car Number: 109
Country: Portugal
[nggallery id=207
Length: 3098
Height: 1299
Width: 1403
Wheelbase: 1590
Track: 1200/1170
Car Weight: 210
Weight Distribution: 135/143
Suspension: Double unequal length, unparallel A-Arms. Pullrod to rocker actuating horizontally oriented damper, spring and ARB/Double unequal length, unparallel A-Arms. Pushrod to rocker actuating damper, spring and ARB
Tyres: 20.5×7.0-13, R25B, Hoosier/20.5×7.0-13, R25B, Hoosier
Wheels: 7×13, 10 mm offset, one piece CFRP rim/7×13, 10 mm offset, one piece CFRP rim
Brakes: Floating, Impax Supreme Steel, hub mounted, 220mm outer diam,, 160mm inner diam/Floating, Impax Supreme Steel, hub mounted, 220mm outer diam,, 160mm inner diam.
Chassis: Two pieces CFRP monocoque
Engine: 2x Siemens 1FE1, AC Synchronous motors
Bore: –
Stroke: –
Cylinders: –
CC: –
Fuel Type: Electric
Fuel System: –
Max Power: 62,8kW@15000
Max Torque: 48Nm@15000
Transmission: 2xTwo stage Helical gears
Differential: Electrical differential (one motor driving each rear wheel)
Final Drive: 21:4.2:1
Team Profile
The FST 05e is the 5th car built by Projecto FST Novabase, during our 13years of history. After participating in Germany and Spain in 2011 and Silverstone in 2012 with our first electric car, we decided to build a much more competitive and lightweight prototype. FST 05e achieved an overall win in Class2 in FS UK 2012 (including a win in the design and business plan events).
We are now aiming to present a reflection of that result this year in Silverstone. Our team consists of 32 enthusiastic students, all extra-curricular, from mechanical, electrical, informatics and aerospace engineering. We are eager to learn as much as possible during this participation in FS UK, and feel free to give us some feedback about our car. We also want to leave a word of gratitude to our Sponsors, always being in our project, and making our dream come true. Visit our team on www.projectofst.com or www.facebook.com/projectofst
